DeSite SLG 108
Hourly Production 30 to 60 yards per hour.
MSRP
$14,990 AU
GST Included
DESIGNED FOR FULL SIZED EQUIPMENT
Wheel Loaders
Backhoes
Compact Wheel Loaders
Skidsteers
Excavators
Compact Excavators
GENERAL DESCRIPTION
The SLG 108 is our largest screener model, specifically designed for use with full-size equipment. With an impressive hourly production capacity of 30 to 60 yards per hour, this screener is built to handle large-scale operations with ease. It is compatible with buckets ranging from 84 to 108 inches, providing flexibility for various equipment sizes. Additionally, the SLG 108 offers over 10 different mesh options, allowing you to efficiently process a wide range of materials to meet your specific needs.
YOU CAN SCREEN
- Wood Mulch
- Decorative Stone
- Road Gravel
- Erosion Control Rock
- Ground Asphalt
- Crushed Concrete
SCREENER FEATURES
TILTING SCREEN DECK
- The ability to adjust the screen deck slope while screening is a key factor in increasing efficiency and boosting hourly production. The 108 Pro Screen offers adjustable positions to accommodate different materials and moisture levels, ensuring optimal performance in all soil conditions—whether wet, dry, sandy, rocky, or even frozen.
- To slow down material flow, the operator simply needs to flatten the deck slope using the bucket while feeding the screener. For high moisture materials, keeping the screener at a steeper slope allows material to travel faster across the deck. This high-efficiency feature is unique to DeSite screening machines, setting them apart in the industry.
- Enhanced Efficiency: Adjusting the screen deck slope improves screening efficiency, resulting in higher hourly production.
- Versatile Performance: The SLG 108 adapts to various materials and moisture levels, ensuring consistent performance in all soil conditions, including wet, dry, sandy, rocky, and frozen soils.
- Controlled Material Flow: Operators can easily control material flow by adjusting the deck slope, slowing it down for better screening of certain materials.
- Optimized for High Moisture: A steeper slope allows for faster material travel, making it ideal for screening high moisture materials.
- Unique to DeSite: This high-efficiency feature is exclusive to DeSite screening machines, offering a distinct advantage in the market.
CANTILEVERED SPRING SUSPENSION SYSTEM
- The Cantilevered Spring Suspension System is designed to be virtually maintenance-free, requiring attention to just two grease points per shift. This advanced system utilizes leaf springs, Z springs, and UHMW bushings to keep the suspension tubes and coils separate, eliminating the need for lubrication. With less time spent on maintenance, you can focus more on screening, leading to increased production and profitability.
- This innovative suspension system allows operators to adjust the deck slope to perfectly match the material being screened. The cantilevered design ensures that when pressure is applied to the top of the screen deck, the bottom moves in the opposite direction, enhancing the screening process. The system's simple yet durable construction provides flexibility and reliability in operation.
- Minimal Maintenance: Requires servicing of only two grease points per shift, reducing downtime and increasing productivity.
- No Lubrication Needed: Utilizes leaf springs, Z springs, and UHMW bushings to separate suspension components, eliminating the need for lubrication.
- Increased Production: Less time spent on maintenance means more time available for screening, boosting overall production and profitability.
- Adjustable Deck Slope: Operators have the flexibility to adjust the deck slope to match the material being screened, optimizing the screening process.
- Efficient Cantilevered Design: The system's cantilevered structure ensures that when the top of the screen deck is pushed down, the bottom moves in the opposite direction, enhancing screening efficiency.
- Durable Construction: Built for reliability and long-term use, offering a simple yet robust solution for various screening needs.
SLG 108
MACHINE SPECIFICATIONS
| MACHINE DIMENSIONS | |
|---|---|
| Machine Width | 126 inches |
| Machine Height | 122 inches |
| Machine Depth | 72 inches |
| SCREEN DECK | |
| Screen Deck Width | 120 inches |
| Screen Deck Length | 72 inches |
| Screen Deck Surface area | 58 sq/ft |
| Screen Deck Tilt Angle | 45 to 30 Degrees |
| WEIGHT | |
| Total Weight with riser box | 5500 lbs |
| Total Weight without riser box | 4300 lbs |
DeSite WARRANTY POLICY
3 year structural warranty.
1 year electrical components warranty.
read more
We provide all parts at no cost to the customer during the warranty period.
Customer is responsible for installing the part and covering the shipping cost.
DeSite Screeners are vibratory screeners.
Customers are responsible for inspection before and after use.
We do not warrant against abuse or lack of maintenance.
DESITE WARRANTY POLICY
BUY WITH CONFIDENCE
ABOUT MESH
Square
- We offer a wide range of mesh that are quick and easily changed.The ability to install large and small high quality mesh makes DeSite SLG Screeners a time saver and money maker. We offer both square and elongated mesh pattern in a double lock crimp weave. Our double lock weave puts two crimps in each wire as they intersect, This creates a strong weave and a stronger, more stable mesh.
MESH GUIDE
Square
| Mesh Size | Pattern | Product Size |
|---|---|---|
| 2" x 2" | Square | 1-1/2" |
| 3" x 3" | Square | 2" |
| 4" x 4" | Square | 3" |
